Sampling method

Suction type

Principle of detection

New Ceramic catalytic Method, Thermal Conductivity Method, Non-Dispersive Infrared Method, Potentiostatic Electrolysis Method, Photo-Ionization Detector

Type of alarm

Gas alarm / fault alarm

Display of alarm

Lamp blinking / buzzer / gas concentration display blinking

Explosion protected construction

Flameproof enclosures + Intrinsic safety

Explosion-proof class

ATEX : II 1G Ex da ia II C T4 Ga/ II 1G Ex ia II C T4 Ga
IECEx: : Ex da ia II C T4 Ga/Ex ia II C T4 Ga

Ingress proof rating

IP66/68

Approvals

Japan Ex, ATEX, IECEx, JIS

CE marking

EMC / ATEX / RoHS

Power source

Lithium ion battery unit [BUL-9000] or
Dry battery unit (AA alkaline battery 6 pcs.) [BUD-9000]

Continuous operation

Approx. 25 hours (fully charged) [Lithium ion battery unit]
Approx. 12 hours (25℃, no alarm, no lighting) [Dry battery unit]
* Varies depending on the mounted sensor.

Dimensions

Approx. 158 (W) × 85 (H) × 132 (D) mm (excluding projections)

Weight

Approx. 1.1 kg (includes battery and battery unit)

Operating temperature range

Temporary ambient conditions : -40 ℃ to +60 ℃ (no sudden changes)
Continuous ambient conditions : -20 ℃ to +50 ℃ (no sudden changes)
* May vary depending on the mounted sensor.

Operating humidity range

Temporary ambient conditions : 0 to 95 %RH (no condensation)
Continuous ambient conditions :10 to 90 %RH (no condensation)
* May vary depending on the mounted sensor.

Operating pressure range

80 to 120 kPa (80 to 110 kPa for explosion-proof range)

Target gas

C2H2, CH4, CL2, CO, CO2, H2, H2S, HCL, i-C4H10, NH3, O2, O3, SO2, VOC
